HARDWARE FEATURES | |
Interface | • 2× 10/100/1000Mbps RJ45 Port • Auto Negotiation/Auto MDI/MDIX • 1× Power Output Port |
Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) • 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m) |
Power Supply | 12VDC 1A, 9VDC 1A, 5VDC 2A |
Basic Function | • Compatible With IEEE 802.3af Compliant PSEs • Delivers Power Up To 100 Meters • Optional 12VDC, 9VDC or 5VDC Power Output |
LED Indicator | PWR |
Dimensions ( W x D x H ) | 3.2*2.1*0.9 in.(80.8*54*24 mm) |
SOFTWARE FEATURES | |
Basic Function | • Compatible With IEEE 802.3af Compliant PSEs • Delivers Power Up To 100 Meters • Optional 12VDC, 9VDC or 5VDC Power Supply |
OTHERS | |
Certification | FCC, CE, RoHS |
Package Contents | • POE10R • Power Cord • Installation Guide |
Environment | • Operating Temperature: 0℃~40℃ (32℉~104℉) • Storage Temperature: -40℃~70℃ (-40℉~158℉) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing |
